Mini HDMI to VGA Adapter Cable 1080P with Audio

A converter for the devices that carry a Mini HDMI socket: compact cameras, camcorders, tablets, single-board computers and games consoles. The Mini HDMI plug goes into the source, the VGA socket takes the monitor, projector or older TV, and a 3.5mm pigtail carries the audio that VGA cannot.

The chipset is built into the plug, so there is nothing to configure and no power brick — the HDMI port supplies what the converter needs. Video passes at up to 1080p, with 720p and 1080i also supported.

Key features

• Mini HDMI (Type-C) male input, VGA female output
• 3.5mm audio pigtail for the sound feed
• Built-in chipset, no external power supply
• Resolution up to 720p / 1080i / 1080p
• Short HDMI tail (approx. 25 cm) with a longer audio lead
• Portable digital-to-analogue conversion for on-location use

Specifications

Two things to set straight. First, VGA is video only, so the audio reaches the display or amplifier through the 3.5mm lead, not through the VGA socket. Second, the factory sheet quotes the audio lead as roughly 120 — we read that as 120 cm; confirm the length you need on the quote, since short and long pigtails are both buildable.

Typical applications

• Getting a camera or camcorder onto a VGA projector
• Running a tablet or Mini-PC to an older VGA monitor
• Bench and field setups where the display is VGA only

Custom and OEM options

Housing colour and finish, cable length, connector plating, printed logo and retail packaging with your own artwork can all be specified. Standard items from 100 pcs, custom builds from 500 pcs, free samples, production in 20–25 working days.
