DC 12V/24V to 5V Step-Down Converter with USB Output
$6.20 – $10.00 / pc · MOQ 500 pcs
Potted, IP68-rated DC step-down converter that turns a 12V or 24V vehicle supply into a regulated 5V 1.5A (7.5W) output on a Micro USB, Mini USB or other USB connector.
- Description
A hard-wired power supply for anything that runs on 5V in a vehicle: take the 12V or 24V feed from the loom, and the converter delivers a regulated 5V to a USB output on the other end. It is the clean solution for a dash cam, a GPS unit, a tablet, a phone, a recorder or a camera that otherwise relies on a plug-in car charger falling out of a socket.
Synchronous rectification keeps efficiency high and heat low, and the whole circuit is sealed in a glue-potted case. That potting is what earns the IP68 rating: water, moisture, dust and vibration are all handled, which is why the same unit is used on motorcycles, boats and industrial equipment as well as in cars.
Key features
- Input 12V or 24V nominal for vehicles and DC systems
- Regulated 5V output, 1.5A / 7.5W, auto-adapting
- Conversion efficiency up to 96%
- Fully glue-potted, IP68 waterproof and shock-resistant
- Over-current, over-heat, short-circuit and reverse-polarity protection
- Multiple output connectors: Micro USB, Mini USB, right-angle Mini USB and more
Specifications
| Input voltage | DC 12V / 24V nominal |
| Input range | DC 8 – 30V |
| Output voltage | DC 5V |
| Output current | 1.5A, auto-adapting |
| Output power | 7.5W |
| Conversion efficiency | Up to 96% |
| Voltage / load regulation | ±1% / ±2% |
| Ripple (full load) | < 150mV |
| No-load current | < 100mA |
| Working temperature | -40 – 80 °C |
| Waterproof rating | IP68 |
| Certification | CE / RoHS / FCC |
| Case | Plastic, potted; anti-shock, anti-moisture, anti-dust |
Two numbers worth reading before you buy. The input range is quoted as DC 8–30V in the specification table and as DC 8–52V in the factory notes — treat the wider figure as design headroom and the narrower one as the guaranteed window, and tell us if your supply can spike above 30V so we can confirm the build. The efficiency figure also appears as both more than 90% and 96%, so size for worst-case heat using the lower bound.
Typical applications
- Dash cams, GPS trackers and reversing monitors on 12V/24V vehicles
- Charging phones and tablets from a hard-wired 5V feed
- Motorcycles, boats, agricultural and industrial equipment
- 5V LED lighting, MP3/MP4 players and portable recorders
Custom and OEM options
Output connector type, cable length, housing finish, printed logo and retail packaging can all be specified. Standard items from 100 pcs, custom builds from 500 pcs, free samples, production in 20–25 working days.
