Micro HDMI Male to Male Cable, Up to 10 m

Micro HDMI ports live on the small end of the display world — tablets, action cameras, mini PCs — and linking two of them directly needs a lead that keeps the digital signal honest at length. This Micro HDMI male-to-male cable carries up to 10.2 Gbps, enough for 1080p deep-colour video plus audio with headroom, and is built in lengths up to 10 m (30 ft) without a repeater.

The construction is specified like a full-size HDMI lead because the signal does not care how small the plug is: HDPE insulation between conductors, bare copper or tinned copper (CCS on request), aluminium foil plus braiding shielding, and an optional ferrite core where the installation sits near power lines. Plugs are 24K gold plated or nickel plated per order, the jacket runs black or white with custom colours, and compliance covers ATC, CE, FCC, RoHS and REACH. Outside diameter is 5.5 mm — slim enough for tight device edges.

Key features

• Micro HDMI male to Micro HDMI male, direct link
• Up to 10.2 Gbps and lengths to 10 m
• 24K gold-plated or nickel-plated connectors
• HDPE insulation, foil plus braid shielding, optional ferrite
• ATC / CE / FCC / RoHS / REACH compliance

Specifications

Typical applications

• Tablet and action-camera direct display links
• Mini PC and media-player installs
• Camera-to-monitor field review rigs
• OEM colourway and packaging programmes

Custom and OEM options

Length, colour, connector finish, ferrite core and packaging (polybag, zip bag, OPP) are all set per order. Tell us the devices and the run length, and we quote the build.

FAQ

Will it fit a standard HDMI socket?
No — both ends are Micro HDMI (type D). For Micro-to-standard runs, see our Micro HDMI to HDMI cable.

Does 10 m still carry full speed?
Yes, at this construction the 10.2 Gbps rating holds across the length range; beyond that we quote active or higher-gauge builds.

Samples, packing options, payment terms and warranty conditions are set out in How to Order and Delivery Information.
